TEC Microsystems - Miniature Thermoelectric Coolers and Sub-Assemblies

ISO9001:2008 Certified



Performance @27ºC, Vacuum

Performance @50ºC, Dry N2

Cold Side

Hot Side

Height

TEC TYPE

dTmax

Qmax

Imax

Umax

ACR

dTmax

Qmax

Imax

Umax

ACR

A

B

C

D

H


K

W

A

V

Ohm

K

W

A

V

Ohm

mm

mm

mm

mm

mm

1MDL06-024-xxAN05

1MDL06-024-03AN05

68

9.3

5.1

3.0

0.44

73

10.1

5.1

3.3

0.49

6.0

6.0

6.0

8.0

1.4

1MDL06-024-05AN05

70

5.8

3.2

3.0

0.72

75

6.3

3.1

3.3

0.80

6.0

6.0

6.0

8.0

1.6

1MDL06-024-07AN05

71

4.2

2.3

3.0

0.99

76

4.6

2.3

3.3

1.10

6.0

6.0

6.0

8.0

1.8

1MDL06-024-09AN05

71

3.3

1.8

3.0

1.26

76

3.6

1.8

3.3

1.41

6.0

6.0

6.0

8.0

2.0

1MDL06-024-12AN05

72

2.5

1.4

3.0

1.67

76

2.7

1.4

3.3

1.87

6.0

6.0

6.0

8.0

2.3

1MDL06-024-15AN05

72

2.0

1.1

3.0

2.08

75

2.2

1.1

3.3

2.33

6.0

6.0

6.0

8.0

2.6

1MDL06-031-xxAN05

1MDL06-031-03AN05

68

12.0

5.1

3.8

0.57

73

13.1

5.1

4.2

0.64

6.0

8.2

6.0

10.0

1.4

1MDL06-031-05AN05

70

7.5

3.2

3.9

0.93

75

8.2

3.1

4.3

1.03

6.0

8.2

6.0

10.0

1.6

1MDL06-031-07AN05

71

5.4

2.3

3.9

1.28

76

5.9

2.3

4.3

1.43

6.0

8.2

6.0

10.0

1.8

1MDL06-031-09AN05

71

4.3

1.8

3.9

1.63

76

4.7

1.8

4.3

1.82

6.0

8.2

6.0

10.0

2.0

1MDL06-031-12AN05

72

3.2

1.4

3.9

2.16

76

3.5

1.3

4.3

2.42

6.0

8.2

6.0

10.0

2.3

1MDL06-031-15AN05

72

2.6

1.1

3.9

2.69

75

2.8

1.1

4.3

3.01

6.0

8.2

6.0

10.0

2.6

1MDL06-035-xxAN05

1MDL06-035-03AN05

68

13.5

5.1

4.3

0.65

73

14.7

5.1

4.8

0.72

6.0

8.2

6.0

10.0

1.4

1MDL06-035-05AN05

70

8.4

3.2

4.4

1.04

75

9.2

3.1

4.8

1.16

6.0

8.2

6.0

10.0

1.6

1MDL06-035-07AN05

71

6.1

2.3

4.4

1.44

76

6.7

2.3

4.8

1.61

6.0

8.2

6.0

10.0

1.8

1MDL06-035-09AN05

71

4.8

1.8

4.4

1.84

76

5.3

1.8

4.8

2.06

6.0

8.2

6.0

10.0

2.0

1MDL06-035-12AN05

72

3.7

1.4

4.4

2.44

76

4.0

1.3

4.8

2.73

6.0

8.2

6.0

10.0

2.3

1MDL06-035-15AN05

72

2.9

1.1

4.4

3.04

76

3.2

1.1

4.8

3.40

6.0

8.2

6.0

10.0

2.6

1MDL06-042-xxAN05

1MDL06-042-03AN05

68

16.2

5.1

5.2

0.77

73

17.6

5.1

5.7

0.86

6.0

10.2

6.0

12.0

1.4

1MDL06-042-05AN05

70

10.1

3.2

5.2

1.25

75

11.0

3.1

5.8

1.40

6.0

10.2

6.0

12.0

1.6

1MDL06-042-07AN05

71

7.4

2.3

5.2

1.73

76

8.0

2.3

5.8

1.93

6.0

10.2

6.0

12.0

1.8

1MDL06-042-09AN05

71

5.8

1.8

5.2

2.21

76

6.3

1.8

5.8

2.47

6.0

10.2

6.0

12.0

2.0

1MDL06-042-12AN05

72

4.4

1.4

5.2

2.93

76

4.8

1.3

5.8

3.27

6.0

10.2

6.0

12.0

2.3

1MDL06-042-15AN05

72

3.5

1.1

5.3

3.65

76

3.9

1.1

5.8

4.08

6.0

10.2

6.0

12.0

2.6

1MDL06-050-xxAN05

1MDL06-050-03AN05

68

19.2

5.1

6.2

0.92

74

20.9

5.1

6.8

1.02

8.0

8.0

8.0

10.0

1.4

1MDL06-050-05AN05

70

12.0

3.2

6.2

1.49

76

13.1

3.1

6.9

1.66

8.0

8.0

8.0

10.0

1.6

1MDL06-050-07AN05

71

8.8

2.3

6.2

2.06

76

9.5

2.3

6.9

2.30

8.0

8.0

8.0

10.0

1.8

1MDL06-050-09AN05

71

6.9

1.8

6.2

2.63

77

7.5

1.8

6.9

2.94

8.0

8.0

8.0

10.0

2.0

1MDL06-050-12AN05

72

5.2

1.4

6.2

3.49

77

5.7

1.3

6.9

3.90

8.0

8.0

8.0

10.0

2.3

1MDL06-050-15AN05

72

4.2

1.1

6.3

4.34

76

4.6

1.1

6.9

4.85

8.0

8.0

8.0

10.0

2.6

1MDL06-052-xxAN05

1MDL06-052-03AN05

68

20.0

5.1

6.4

0.96

73

21.8

5.1

7.1

1.07

6.0

12.2

6.0

14.0

1.4

1MDL06-052-05AN05

70

12.5

3.2

6.5

1.55

76

13.6

3.1

7.1

1.73

6.0

12.2

6.0

14.0

1.6

1MDL06-052-07AN05

71

9.1

2.3

6.5

2.14

76

9.9

2.3

7.1

2.39

6.0

12.2

6.0

14.0

1.8

1MDL06-052-09AN05

71

7.2

1.8

6.5

2.74

76

7.8

1.8

7.1

3.06

6.0

12.2

6.0

14.0

2.0

1MDL06-052-12AN05

72

5.4

1.4

6.5

3.63

76

5.9

1.3

7.2

4.05

6.0

12.2

6.0

14.0

2.3

1MDL06-052-15AN05

72

4.4

1.1

6.5

4.52

76

4.8

1.1

7.2

5.05

6.0

12.2

6.0

14.0

2.6

1MDL06-068-xxAN05

1MDL06-068-03AN05

68

26.1

5.1

8.4

1.25

73

28.5

5.1

9.3

1.39

7.0

14.0

7.0

16.0

1.4

1MDL06-068-05AN05

70

16.4

3.2

8.5

2.03

76

17.8

3.1

9.3

2.26

7.0

14.0

7.0

16.0

1.6

1MDL06-068-07AN05

71

11.9

2.3

8.5

2.80

76

13.0

2.3

9.3

3.13

7.0

14.0

7.0

16.0

1.8

1MDL06-068-09AN05

71

9.4

1.8

8.5

3.58

76

10.2

1.8

9.3

4.00

7.0

14.0

7.0

16.0

2.0

1MDL06-068-12AN05

72

7.1

1.4

8.5

4.74

76

7.7

1.3

9.4

5.30

7.0

14.0

7.0

16.0

2.3

1MDL06-068-15AN05

72

5.7

1.1

8.5

5.91

76

6.2

1.1

9.4

6.60

7.0

14.0

7.0

16.0

2.6


STANDARD 1MDL06 SERIES THERMOELECTRIC COOLERS (AlN 0.5mm Ceramics)

1MDL06 TE COOLERS ADVANTAGES

1MDL06 TE COOLERS KEY FEATURES

◻︎ High-Density (HD) Pellets Placement

◻ Cold Side from 6x6mm2 up to 7x15mm2

◻ Elongated TEC shape for DWDM packages

◻ Al2O3, AlN and mixed ceramics combinations

◻ High-quality bulk BiTe material

◻ Accurate steam soldering technology

◻ RoHS compliant TE Coolers by default

◻ Telcordia GR-468 qualified TECs

(placeholder)

1MDL06

TECs on AlN

ceramics 0.25mm

1MDL06

TECs on AlN

ceramics 0.5mm

1MDL06

TECs on Al2O3

ceramics 0.25mm

1MDL06

TECs on Al2O3

ceramics 0.5mm

Thermoelectric coolers of MDL06 Series are technically the dimensional analogs of ML06 Series, but have up to 100% higher cooling capacity on the same size.  MDL06 TECs are optimized by shape and terminal connection methods for the standard DWDM packages like "Butterfly" 14pin or DIL.  Additionally to default Al2O3 ceramics all MDL06 TECs can be manufactured on AlN ceramics for better temperature uniformity among TEC surface (optimal in case of direct mounting to TEC cold side without a separate optical bench).  MDL06 TECs are assembled with HD pellets placement technology using RoHS compliant Sn-Sb solder with a melting temperature Tmelt=230ºC.  Thermoelectric coolers of MDL06 Series meet Telcordia GR-486 standard requirements.  Wide range of TEC manufacturing options is available.  The standard and most common MDL06 Series TECs on AlN (0.5mm) ceramics are listed in the table below.  Detailed TEC drawings, 3D models, performance plots and estimations for particular application conditions are provided by request.
